SS 316/ 316L Threaded Flange

Threaded Flange

ASTM A182 SS 316 Threaded Flange

UNS S31600, 1.4401, SUS 316, ASTM A182 F316 Threaded Flanges

Threaded Flange

Stainless Steel 316 Screwed Flange

UNS S31600, 1.4436, AISI 316, ASTM A182 F316 Screwed Flange

Threaded Flange

ASTM A182 SS 316L Threaded Flange

UNS S31603, 1.4404, AISI 316L, ASTM A182 F316L Threaded Flange

Threaded Flange

Stainless Steel 316L Raised Face Threaded Flange

UNS S31603, 1.4435, SUS 316L, ASTM A182 F316L Threaded Raised Face Flange

Hex Forge Inc is a well-known organization. We manufacture the best A182 F316/316L Threaded Flange in the market. They are made of stainless steel alloys that can withstand phosphoric acid and other chemicals and gases—used in the food and pharmaceutical manufacturing industries. They are capable of handling heated organic and fatty acids without becoming polluted. Even if the water contains a high degree of chlorides, these ASTM A182 SS 316 Threaded Flanges operate effectively in freshwater applications. Because of the low carbon concentration, these are easy to weld and have a long lifespan.

When used in intermittent service applications at a temperature of 870°C, ASTM a182 SS 316 Threaded Flange offers strong oxidation resistance. The suggested temperature for the a182 SS 316 Threaded Flange in an application that needs continuous service is around 925°C. However, the use of flange f316 at temperatures ranging from 425°C to 860°C is not suggested. Due to its strong resistance to carbide precipitation, the low carbon variant of ss ASTM a182 gr SS 316 is recommended in cases like these. A higher carbon content version of the stainless steel ASTM a182-SS 316 is recommended for applications requiring solid tensile strength at temperatures exceeding 500°C.

ASTM A182 STAINLESS STEEL 316 FLAT FACE THREADED FLANGES MANUFACTURER, SS A182 F316 BSP THREADED FLANGE, ASME SA182 SS 316L SCREW FLANGE, SS 316L THREADED FLANGE SUPPLIER.

Table of Content

316L STAINLESS STEEL RAISED FACED THREADED FLANGES PRICE, STAINLESS STEEL S31603 SCREWED FLANGE STOCKIST IN MUMBAI, INDIA.

Power generation, chemical equipment, paper, and pulp industries, petrochemical, pharmaceutical, nuclear facilities, aerospace industries, oil and gas processing, and other industries use SS 316 / 316L Threaded Flange. A few tests, such as fumigation and raw material testing, are carried out to ensure the product’s quality. After completing these testing, the product is sent for packing with high-quality materials.

Specification And Material Grade Of SS 316 / 316L Threaded Flange

Specification : ASTM A182 / ASME SA182

Standard : ANSI/ASME B16.5, B16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, GOST Flange, ASME/ANSI B16.5/16.36/16.47A/16.47B, MSS SP44, ISO70051, JISB2220, BS1560-3.1, API7S-15, API7S-43, API605, EN1092

Size : 1/2″ (15 NB) to 48″ (1200NB) DN10~DN5000

Class : 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS, DIN Standard ND-6,10, 16, 25, 40 Etc.

Connect Type/ Flange Face Type : Raised Face (RF), Ring Type Joint (RTJ), Flat Face (FF), Large Male-Female (LMF), Small Male-Female (SMF)

JIS : JIS B2220, JIS B2221, 5K, 10K, 16K, 20K, 30K, 40K, 63K

DIN : DIN 2527, DIN 2566, DIN 2573, DIN 2576, DIN 2641, DIN 2642, DIN 2655, DIN 2656, DIN 2627, DIN 2628, DIN 2629, DIN 2631, DIN 2632, DIN 2633, DIN 2634, DIN 2635, DIN 2636, DIN 2637, DIN 2638, DIN 2673

BS : BS 4504, BS 4504, BS 1560, BS 10

Screwed Flange Drawing
Stainless Steel 316/ 316L Threaded Flange

Equivalent Grades Of Stainless Steel 316 / 316L Threaded Flanges

STANDARD WERKSTOFF NR. UNS JIS BS GOST AFNOR EN
SS 316 1.4401 / 1.4436 S31600 SUS 316 316S31 / 316S33 – Z7CND17‐11‐02 X5CrNiMo17-12-2 / X3CrNiMo17-13-3
SS 316L 1.4404 / 1.4435 S31603 SUS 316L 316S11 / 316S13 03Ch17N14M3 / 03Ch17N14M2 Z3CND17‐11‐02 / Z3CND18‐14‐03 X2CrNiMo17-12-2 / X2CrNiMo18-14-3

WE MANUFACTURE ASTM A182 STAINLESS STEEL 316 THREADED FLANGE AS PER INTERNATIONAL STANDARDS & SPECIFICATIONS. 316L SCREWED FLANGES MANUFACTURERS IN INDIA, CUSTOM SIZES SS 316/316L THREADED FLANGE CAN BE PRODUCED AS PER CLIENT DRAWING.

Dimensional Standards
  • American Standard (ANSI/ASME/AWWA)
  • German Standard (DIN)
  • European Standard (EN)
  • Japanese Standard (JIS)
  • British Standard (BS)
  • MSS Standard (MSS-SP)
  • Petroleum Standard (API)
  • Russian Standard (GOST)
  • South African Standard (SABS / SANS)
Manufacturing Facilities :
  • Raw material cutting: band saw
  • Cold Forging
  • Open / Close Die Forging & Rolling: Hammer / Press / Ring Rolling
  • Machining: CNC lathes/SPM lathes
  • Bolt Hole drilling: High speed CNC Vertical Machining Center
  • Heat treatment: Solution Annealing (batch annealing furnaces)
  • Seamless Rolled Ring Forging

SS 316 / 316L Threaded Flange Pressure Rating

ASME B16.5 Threaded Flange Pressure Ratings
Temperature (°C) Class
Class 150 Class 300 Class 400 Class 600 Class 900 Class 1500 Class 2500
-29 – 38 19.8 51.7 68.9 103.4 155 259 431
50 19.5 51.7 68.9 103.4 155 259 431
100 17.7 51.5 68.7 103.0 155 258 429
150 15.8 50.2 66.8 100.3 151 251 418
200 13.8 48.6 64.8 97.2 146 243 405
250 12.1 46.3 61.7 92.7 139 232 386
300 10.2 42.9 57.0 85.7 129 214 357
325 9.3 41.4 55.0 82.6 124 207 344
350 8.4 40.0 53.4 80.0 120 200 334
375 7.4 37.8 50.4 75.7 114 189 315
400 6.5 34.7 46.3 69.4 104 174 290
425 5.5 28.8 38.4 57.5 86.3 144 240
450 4.6 23.0 30.7 46.0 69.0 115 192
475 3.7 17.1 22.8 34.2 51.3 85.4 142
500 2.8 11.6 15.4 23.2 34.7 57.9 96.5
538 1.4 5.9 7.9 11.8 17.7 29.5 49.2

316/316L SS Standard Threaded Flange Sizes Chart

DN In inches Dimension ASME B16.5 Dimensional Sizes 1/2 inches to 2 1/2 inches
125 LBS 150 LBS 300 LBS 400 LBS 600 LBS 900 LBS 1500 LBS 2500 LBS
inches millimeter inches millimeter inches millimeter inches millimeter inches millimeter inches millimeter inches millimeter
1/2 A 3 1/2 88.9 3 3/4 95.2 3 3/4 95.2 3 3/4 95.2 4 3/4 121 4 3/4 121 5 1/4 133.4
b 7/16 11.1 9/16 14.3 9/16 14.3 9/16 14.3 7/8 22.2 7/8 22.2 1 3/16 30.2
D2 1 3/8 34.9 1 3/8 34.9 1 3/8 34.9 1 3/8 34.9 1 3/8 34.9 1 3/8 34.9 1 3/8 34.9
D1 2 3/8 60.3 2 5/8 66.7 2 5/8 66.7 2 5/8 66.7 3 1/4 82.6 3 1/4 82.6 3 1/2 88.9
n 4 4 4 4 4 4 4 4 4 4 4 – 4 44
d 5/8 15.9 5/8 15.9 5/8 15.9 5/8 15.9 7/8 22.2 7/8 22.2 7/8 22.2
3/4 A 3 7/8 98.4 4 5/8 117.5 4 5/8 117.5 4 5/8 117.5 5 1/8 130 5 1/8 130 5 1/2 139.7
b 1/2 12.7 5/8 15.9 5/8 15.9 5/8 15.9 1 25.4 1 25.4 1 1/4 31.8
D2 1 11/16 42.9 1 11/16 42.9 1 11/16 42.9 1 11/16 42.9 1 11/16 42.9 1 11/16 42.9 1 11/16 42.9
D1 2 3/4 69.8 3 1/4 82.5 3 1/4 82.5 3 1/4 82.5 3 1/2 88.9 3 1/2 88.9 3 3/4 95.2
n 4 4 4 4 4 4 4 4 4 4 4 – 4 44
d 5/8 15.9 3/4 19 3/4 19 3/4 19 7/8 22.2 7/8 22.2 7/8 22.2
1 A 4 1/4 108 4 7/8 123.8 4 7/8 123.8 4 7/8 123.8 5 7/8 149.2 5 7/8 149.2 6 1/4 159
b 9/16 14.3 11/16 17.5 11/16 17.5 11/16 17.5 1 1/8 28.6 1 1/8 28.6 1 3/8 34.9
D2 2 50.8 2 50.8 2 50.8 2 50.8 2 50.8 2 50.8 2 50.8
D1 3 1/8 79.4 3 1/2 88.9 3 1/2 88.9 3 1/2 88.9 4 102 4 102 4 1/4 108
n 4 4 4 4 4 4 4 4 4 4 4 4 4 4
d 5/8 15.9 3/4 19 3/4 19 3/4 19 1 25.4 1 25.4 1 25.4
1 1/4 A 4 5/8 117.5 5 1/4 133.4 5 1/4 133.4 5 1/4 133.4 6 1/4 159 6 1/4 159 7 1/4 184.2
b 5/8 15.9 3/4 19 13/16 20.6 13/16 20.6 1 1/8 28.6 1 1/8 28.6 1 1/2 38.1
D2 2 1/2 63.5 2 1/2 63.5 2 1/2 63.5 2 1/2 63.5 2 1/2 63.5 2 1/2 63.5 2 1/2 63.5
D1 3 1/2 88.9 3 7/8 98.4 3 7/8 98.4 3 7/8 98.4 4 3/8 111 4 3/8 111 5 1/8 130
n 4 4 4 4 4 4 4 4 4 4 4 4 4 4
d 5/8 15.9 3/4 19 3/4 19 3/4 19 1 25.4 1 25.4 1 1/8 28.6
1 1/2 A 5 127 6 1/8 155.6 6 1/8 155.6 6 1/8 155.6 7 177.8 7 177.8 8 203
b 11/16 17.5 13/16 20.6 7/8 22.2 7/8 22.2 1 1/4 31.8 1 1/4 31.8 1 3/4 44.5
D2 2 7/8 73 98 2 7/8 73 2 7/8 73 2 7/8 73 2 7/8 73 2 7/8 73 2 7/8 73
D1 3 7/8 4 4 1/2 114 4 1/2 114 4 1/2 114 4 7/8 124 4 7/8 124 5 3/4 146
n 4 4 4 4 4 4 4 4 4 4 4 4 4 4
d 5/8 . 15.9 7/8 22.2 7/8 22.2 7/8 22.2 1 1/8 28.6 1 1/8 28.6 1 1/4 31.8
2 A 6 152.4 6 1/2 165.1 6 1/2 165.1 6 1/2 165.1 8 1/2 215.9 8 1/2 215.9 9 1/4 234.9
b 3/4 19 7/8 22.2 1 25.4 1 25.4 1 1/2 38.1 1 1/2 38.1 2 50.8
D2 3 5/8 92.1 3 5/8 92.1 3 5/8 92.1 3 5/8 92.1 3 5/8 92.1 3 5/8 92.1 3 5/8 92.1
D1 4 3/4 121 5 127 5 127 5 127 6 1/2 165.1 6 1/2 165.1 6 3/4 171
n 4 4 8 8 8 8 8 8 8 8 8 8 8 8
d 3/4 19 3/4 19 3/4 19 3/4 19 1 25.4 1 25.4 1 1/8 28.6
2 1/2 A 7 177.8 7 1/2 190.5 7 1/2 190.5 7 1/2 190.5 9 5/8 244 9 5/8 244 10 1/2 266.7
b 7/8 22.2 1 25.4 1 1/8 28.6 1 1/8 28.6 1 5/8 41.3 1 5/8 41.3 2 1/4 57.2
D2 4 1/8 104.8 4 1/8 104.8 4 1/8 104.8 4 1/8 104.8 4 1/8 105 4 1/8 105 4 1/8 105
D1 5 1/2 139.7 5 7/8 149.2 5 7/8 149.2 5 7/8 149.2 7 1/2 190.5 7 1/2 190.5 7 3/4 197
n 4 4 8 8 8 8 8 8 8 8 8 8 8 8
d 3/4 19 7/8 22.2 7/8 22.2 7/8 22.2 1 1/8 28.6 1 1/8 28.6 1 1/4 31.8

Weight Chart Of Stainless Steel 316 / 316L Threaded Flange

CLASS Nominal Pipe Size Threaded Flange
150 lb ½ 1
¾ 2
1 2
1¼ 3
1½ 3
2 5
2½ 8
3 9
3½ 12
4 13
5 15
6 19
8 30
10 43
12 64
14 90
16 98
18 130
20 165
22 185
24 220
300 lb ½ 2
¾ 3
1 3
1¼ 4.5
1½ 6.5
2 7
2½ 10
3 14
3½ 17
4 24
5 31
6 39
8 58
10 81
12 115
14 165
16 220
18 280
20 325
22 370
24 490
400 lb ½ 2
¾ 3
1 3.5
1¼ 4.5
1½ 6.5
2 8
2½ 12
3 15
3½ 21
4 26
5 31
6 44
8 67
10 91
12 130
14 191
16 253
18 310
20 378
22 405
24 539
600 lb ½ 2
¾ 3
1 4
1¼ 5
1½ 7
2 9
2½ 13
3 16
3½ 21
4 37
5 63
6 80
8 115
10 177
12 215
14 259
16 366
18 476
20 612
22 590
24 876
900 lb ½ 6
¾ 6
1 7.5
1¼ 10
1½ 14
2 22
2½ 31
3 36
4 53
5 83
6 110
8 172
10 245
12 326
14 400
16 459
18 647
20 792
24 1480
1500 lb ½ 6
¾ 6
1 8
1¼ 10
1½ 14
2 25
2½ 36
3 48
4 73
5 132
6 165
8 260
10 436
12 667
14 940
16 1250
18 1625
20 2050
24 2825
2500 lb ½ 7
¾ 9
1 12
1¼ 18
1½ 25
2 38
2½ 55
3 83
4 127
5 210
6 323
8 485
10 925
12 1300

ASTM A182 SS 316/316L Threaded Flange Chemical Composition

Grade C Mn Si P S Cr Mo Ni Fe
SS 316 0.08 max 2.0 max 1.0 max 0.045 max 0.030 max 16.00 – 18.00 2.00 – 3.00 11.00 – 14.00 67.845 min
SS 316L 0.035 max 2.0 max 1.0 max 0.045 max 0.030 max 16.00 – 18.00 2.00 – 3.00 10.00 – 14.00 68.89 min

316/316L Stainless Steel Threaded Flange Mechanical Properties

Grade Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
SS 316 8.0 g/cm3 1400 °C (2550 °F) Psi – 75000 , MPa – 515 Psi – 30000 , MPa – 205 35 %
SS 316L 8.0 g/cm3 1399 °C (2550 °F) Psi – 75000 , MPa – 515 Psi – 30000 , MPa – 205 35 %
