Home » Stainless Steel 310S Hex Bolt
UNS S31008, 1.4845, SUS 310S, ASTM A193 Stainless Steel 310S Fasteners
UNS S31008, 1.4845, SUS 310S, ASTM A193 Stainless Steel 310S Hex Bolt
UNS S31008, 1.4845, SUS 310S, ASTM A193 Stainless Steel 310S Hex Cap Screw
UNS S31008, 1.4845, SUS 310S, ASTM A193 Stainless Steel 310S Heavy Hex Bolt
Due to the low carbon content of ASTM A193 Stainless Steel 310S Hex Bolt, they are designed for use in high-temperature applications. If subsequent aqueous corrosion resistance is necessary, continuous use of SS 310S Hex Bolts in the 800 Degree F – 1580 Degree F range is not suggested. At our production units, these Alloy 310 Hex Bolts are made using supreme quality raw materials that are sourced from reliable sources in the industry.
We are exporting Stainless Steel 310S Hex Bolts, SS 310S Bolts in UAE, Egypt, Jordan, United Kingdom, Kuwait, Eastern Europe, Oman, Qatar, Nigeria, Bahrain etc.
Specification : ASTM A193 / ASME SA193
Size : M3 – M56 | 3/6″ to 2″ | Custom Sizes
Length : 3 to 200 mm
Standard : ISO, ASTM, DIN, JIS, IS, GB, BS, and all International Standards
DIN Standard : B.S. DIN 931, DIN 933, DIN 912, DIN 934, DIN 6923, DIN 603, DIN 7981, DIN 970, DIN916, DIN 7982, DIN 7985, DIN 913
UTS : NPT, UNS, UNF, UNC, UNEF, NPTF
ISO : ISO 4033, ISO 4032, ISO 7380, ISO 4017, JIS standards
Threads : METRIC, BSW, UNC, UNF, BSF or as required
STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
SS 310S | 1.4845 | S31008 | SUS 310S | – | 03Х18Н11 | Z3CN18‐10 | X2CrNi18-9 / X2CrNi19-11 |
We Manufacture Stainless Steel 310S Hex Bolts As Per International Standards & Specifications. 310S SS Hex Bolt Manufacturers In India, Custom Sizes SS 310S Flanged/Tap/Shoulder Hex Bolt Can Be Produced As Per Client Drawing.
Diameter (D) | Thread Lengths (T) | Across the Flats (F) | Body Diameter (D) | Head Height (H) | Across the Corners © | |||||
< 6” | > 6” | MAXIMUM | MINIMUM | MAXIMUM | MINIMUM | MAXIMUM | MINIMUM | MAXIMUM | MINIMUM | |
1 | 2.25 | 2.5 | 1.625 | 1.575 | 1.022 | 0.976 | 0.7 | 0.591 | 1.876 | 1.796 |
1/2 | 1.25 | 1.5 | 0.875 | 0.85 | 0.515 | 0.482 | 0.364 | 0.302 | 1.01 | 0.969 |
2 | 4.25 | 4.5 | 3.125 | 3.025 | 2.039 | 1.964 | 1.388 | 1.175 | 3.608 | 3.449 |
3 | 6.25 | 6. | 4.625 | 4.475 | 3.081 | 2.961 | 2.06 | 1.815 | 5.34 | 5.102 |
3/4 | 1.75 | 2 | 1.25 | 1.212 | 0.768 | 0.729 | 0.524 | 0.455 | 1.443 | 1.383 |
5/8 | 1.5 | 1.75 | 1.062 | 1.031 | 0.642 | 0.605 | 0.444 | 0.378 | 1.227 | 1.175 |
7/8 | 2 | 2.25 | 1.438 | 1.394 | 0.895 | 0.852 | 0.604 | 0.531 | 1.66 | 1.589 |
1 1/2 | 3.25 | 3.5 | 2.375 | 2.3 | 1.531 | 1.47 | 1.036 | 0.902 | 2.742 | 2.622 |
1 1/4 | 2.75 | 3 | 2 | 1.938 | 1.277 | 1.223 | 0.876 | 0.749 | 2.309 | 2.209 |
1 1/8 | 2.5 | 2.75 | 1.812 | 1.756 | 1.149 | 1.098 | 0.78 | 0.658 | 2.093 | 2.002 |
1 3/4 | 3.75 | 4 | 2.75 | 2.662 | 1.785 | 1.716 | 1.196 | 1.054 | 3.175 | 3.035 |
1 3/8 | 3 | 3.25 | 2.188 | 2.119 | 1.404 | 1.345 | 0.94 | 0.81 | 2.526 | 2.416 |
2 1/2 | 5.25 | 5.5 | 3.875 | 3.75 | 2.559 | 2.461 | 1.708 | 1.479 | 4.474 | 4.275 |
2 1/4 | 4.75 | 5 | 3.5 | 3.388 | 2.305 | 2.214 | 1.548 | 1.327 | 4.041 | 3.862 |
2 3/4 | 5.75 | 6 | 4.25 | 4.112 | 2.827 | 2.711 | 1.869 | 1.632 | 4.907 | 4.688 |
NOMINAL SIZE (D) | ACROSS THE FLATS | HEAD THICKNESS | DIAMETER OF BODY | ACROSS Bolt CORNERS | ||||
F (MAXIMUM) | F (MINIMUM) | H (MAXIMUM) | H (MINIMUM) | D (MAXIMUM) | D (MINIMUM) | C (MAXIMUM) | C (MINIMUM) | |
m10 | 17.00 | 15.73 | 6.63 | 6.17 | 10.00 | 9.78 | 18.48 | 17.77 |
m12 | 19.00 | 17.73 | 7.76 | 4.24 | 12.00 | 11.73 | 20.78 | 20.03 |
m14 | 22.00 | 20.67 | 9.09 | 8.51 | 14.00 | 13.73 | 24.25 | 23.35 |
m16 | 24.00 | 23.67 | 10.32 | 9.68 | 16.00 | 15.73 | 27.71 | 26.75 |
m20 | 30.00 | 29.16 | 12.88 | 12.12 | 20.00 | 19.67 | 34.64 | 32.95 |
m24 | 36.00 | 35.00 | 15.44 | 14.56 | 24.00 | 23.67 | 41.57 | 39.55 |
m30 | 46.00 | 45.00 | 19.48 | 17.92 | 30.00 | 29.67 | 53.12 | 50.85 |
m36 | 55.00 | 53.80 | 23.38 | 21.63 | 36.00 | 35.61 | 63.51 | 60.79 |
m42 | 65.00 | 62.90 | 26.97 | 25.03 | 42.00 | 41.38 | 75.06 | 71.71 |
m48 | 75.00 | 72.60 | 31.07 | 28.93 | 48.00 | 47.38 | 86.60 | 82.76 |
m56 | 85.00 | 82.20 | 36.2 | 33.80 | 56.00 | 55.26 | 98.15 | 93.71 |
m64 | 95.00 | 91.80 | 41.32 | 38.68 | 64.00 | 63.26 | 109.70 | 104.65 |
m72 | 105.00 | 101.40 | 46.45 | 43.55 | 72.00 | 71.26 | 121.24 | 115.60 |
m80 | 115.00 | 111.00 | 51.58 | 48.42 | 80.00 | 79.26 | 132.72 | 126.54 |
m90 | 130.00 | 125.50 | 57.74 | 54.26 | 90.00 | 89.13 | 150.11 | 143.07 |
m100 | 145.00 | 140.00 | 63.9 | 60.10 | 90.00 | 99.13 | 167.43 | 159.60 |
Dia Length |
M12 | M16 | M20 | M22 | M24 | M27 | M30 | M36 |
30 | 49.1 | |||||||
35 | 53.6 | |||||||
40 | 58.0 | 105 | ||||||
45 | 62.1 | 113 | 188 | |||||
50 | 66.6 | 121 | 200 | 257 | ||||
55 | 71.0 | 129 | 212 | 272 | ||||
60 | 75.4 | 137 | 225 | 286 | 362 | |||
65 | 79.9 | 145 | 237 | 301 | 380 | |||
70 | 84.3 | 153 | 249 | 316 | 398 | 532 | ||
75 | 88.8 | 160 | 262 | 331 | 415 | 554 | 701 | |
80 | 93.2 | 168 | 274 | 346 | 433 | 576 | 728 | |
85 | 97.6 | 176 | 286 | 361 | 451 | 599 | 756 | 1184 |
90 | 102 | 184 | 298 | 375 | 467 | 621 | 784 | 1224 |
95 | 107 | 192 | 310 | 390 | 485 | 644 | 812 | 1264 |
100 | 199 | 322 | 405 | 503 | 665 | 838 | 1304 | |
105 | 207 | 335 | 420 | 520 | 688 | 865 | 1336 | |
110 | 215 | 347 | 435 | 538 | 710 | 893 | 1376 | |
115 | 223 | 359 | 450 | 556 | 732 | 921 | 1415 | |
120 | 231 | 372 | 465 | 574 | 755 | 949 | 1455 | |
125 | 239 | 384 | 479 | 591 | 777 | 976 | 1495 | |
130 | 247 | 396 | 494 | 609 | 800 | 1004 | 1535 | |
135 | 409 | 509 | 627 | 822 | 1032 | 1575 | ||
140 | 421 | 524 | 645 | 845 | 1059 | 1615 | ||
145 | 433 | 539 | 662 | 867 | 1087 | 1655 | ||
150 | 446 | 554 | 680 | 890 | 1115 | 1695 | ||
155 | 458 | 569 | 698 | 912 | 1143 | 1735 | ||
160 | 584 | 716 | 935 | 1170 | 1775 | |||
165 | 599 | 733 | 957 | 1198 | 1815 | |||
170 | 751 | 979 | 1226 | 1855 | ||||
175 | 769 | 1002 | 1254 | 1895 | ||||
180 | 787 | 1024 | 1281 | 1935 | ||||
185 | 804 | 1047 | 1309 | 1974 | ||||
190 | 822 | 1069 | 1337 | 2014 | ||||
195 | 840 | 1092 | 1365 | 2054 | ||||
200 | 1114 | 1392 | 2094 |
Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
SS 310S | 0.08 max | 2.0 max | 1.00 max | 0.045 max | 0.030 max | 24.00 – 26.00 | 0.75 max | 19.00 – 21.00 | 53.095 min |
Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
7.9 g/cm3 | 1402 °C (2555 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 40 % |
